400MHz/2.4GHz/5.8GHz 3 Band Cavity Diplexer Combiner Multiplexer For WiFi IOT Wireless Communication

400MHz/2.4GHz/5.8GHz 3 Band Cavity Diplexer Combiner Multiplexer For WiFi IOT Wireless Communication

$62.00USD
$62.00USD
Promotion Épuisé
Frais d'expédition calculés à l'étape de paiement.
COLOR

ACASOM  IOT Four Band Cavity Diplexer/Combiner

Working Band1:  5150-5850MHz

Working Band2:  2400-2484MHz

Working Band3:  400-960MHz

Out of Band Rejection：≥85dB

DESCRIPTION

The IOT 3 bands cavity diplexer combines 400-960MHz, 2400-2484, and 5150-5850MHz, and uses for WIFI and IOT wireless network. This component has ultra-low insertion loss and good out-of-band suppression at other bands from a distance of side frequency.

FEATURES

  • Out of Band Rejection：≥85dB

  • Ultra Low Insertion Loss (0.3 dB nominal)

  • Industrial Grade

  • Reduce Interference and Improve Performance

INCLUDED

1* PCS Cavity Combiner

Afficher tous les détails
