ACASOM IOT 600-6000MHz Microstrip Line Directional Coupler
Working Band: 600-6000MHz
DESCRIPTION
The IOT Wideband 10dB Directional coupler is rated for a minimum frequency of 600MHz and a maximum frequency of 6000MHz. The Wideband 10dB Directional Coupler has 0.3dB insertion loss, and 1.2 VSWR. The Wideband 10dB Directional Coupler features rugged aluminum construction and is used indoors. The Wideband 10dB Directional Coupler has a female type N input, a female type N output, and a female type N couple port.
FEATURES
-
Ultra Low Insertion Loss (0.3 dB nominal)
-
Industrial Grade
-
Max 43dBm operating input power range
INCLUDED
1* PCS Directional Coupler
