868MHz Power Divider 915MHz Power Splitter 3-Way Helium Power Divider SMA-Type

Number

Items

Specifications

1

Frequency Band

800-1000MHz

2

Output ports

3-ways

3

Insertion Loss

≤4.9dB

4

Ripple

≤0.2dB

5

Return Loss

≤1.2: 1

6

Isolation

≥30dB

7

Amplitude Balance

0.2dB

8

Phase Balance

3°

9

Impedance

50 Ohms

10

PowerHanding

50W

11

Operating Temperature

-40℃～75℃

12

RF Connector

SMA-Female

13

Surface Finish

Black Paint

14

Dimensions

-

15

Weight

0.35Kg
